Daikin 2-Zone Wall Mounted Ductless Mini-Split 18000 BTU Heat Pump Air Conditioner 12k + 12k - 17 SEER
{
$el.scrollIntoView({ behavior: 'smooth', block: 'start' });
})
"
:class="currentTab === 1 && '!bg-light-blue !text-white'"
class="lg:hidden flex w-full items-center justify-between bg-lighter-grey rounded py-5 px-3 text-base font-primary uppercase text-light-blue transition my-1">
Overview
Daikin’s Multi-Zone Systems are ideal for multi-room applications desiring individual room comfort in a space-saving design. With the ability to connect two wall-mounted indoor units to a single outdoor unit, this compact and simple solution can provide additional comfort to spaces where other solutions may not be viable. In addition, with a small outdoor unit footprint, the Daikin CIRRA Multi-Zone unit takes up less space on a patio or balcony (compared to other Daikin Multi-Zone outdoor units). Suitable for new build and renovation projects, Daikin Multi-Zone Systems are an innovative, reliable solution for your home or space.
Features:
10 Years Parts Warranty (Check Manuals & Specification Tables).
Cooling Capacity: (6,000 min ~ 17,500 max. BTU) 17 SEER Efficiency.
Heating Capacity: (5,000 min ~ 18,000 max BTU) 9 HSPF Efficiency
Daikin 2-Zone CIRRA Series has a small condenser cabinet with Blue Fin Protection and anti-corrosion treatment on the heat exchanger. Pre-charged for up to 98-1/2 ft.
Additional Features:
Eco+
Blue Fin Protection
Simplified Maintenance
Anti-Corrosion Treatment on Heat Exchanger
Quick Warming Function
Automatic Defrosting
Reduced size and footprint compared to other Daikin Multi-Zone outdoor units.
Operating Cooling Ranger: 50° - 115°F
Operating Heating Range: 5° - 65°F
WHAT’S INCLUDED
Your Daikin Ductless Mini-Split Inverter Air Conditioner Heat Pump System Comes With:
CTX12AXVJU | Indoor Unit
CTX12AXVJU | Indoor Unit
2MX18AXVJU | Outdoor Unit
MANUFACTURER’S WARRANTY
10-year parts warranty
at a glance
Brand:
Daikin
System Model Number
2MX18AXVJU + CTX12AXVJU + CTX12AXVJU
Indoor 1 Model Number
CTX12AXVJU
Indoor 2 Model Number
CTX12AXVJU
Outdoor Model Number
2MX18AXVJU
System Heating Capacity (BTU)
17,000
System Cooling Capacity (BTU)
17,000
Aplication Area
550 + 550 SqFt
Manufacturer Limited Warranty (years)
10 Year Parts Warranty
Mounting Type
Wall Mount
Voltage System
208/230 V
Efficiency
17 Seer
Application
Heat Pump / Heating & Cooling
System Shipping Weight
117.0
Bundle includes 3 items
12,000 BTU Multi-zone Wall-Mount Fan Coil Unit CTX12AXVJU
Model Number: CTX12AXVJU
SKU: HCDNA2770
12,000 BTU Multi-zone Wall-Mount Fan Coil Unit CTX12AXVJU
Model Number: CTX12AXVJU
SKU: HCDNA2770
18,000 BTU Daikin Cirra Multi-Zone Outdoor Heat Pump Unit Up to 17 SEER 2MX18AXVJU
Model Number: 2MX18AXVJU
SKU: HCDNA2768
{
$el.scrollIntoView({ behavior: 'smooth', block: 'start' });
})
"
:class="currentTab === 2 && '!bg-light-blue !text-white'"
class="lg:hidden flex w-full items-center justify-between bg-lighter-grey rounded py-5 px-3 text-base font-primary uppercase text-light-blue transition my-1">
Technical
System Specifications
System Model Number
2MX18AXVJU + CTX12AXVJU + CTX12AXVJU
Indoor 1 Model Number
CTX12AXVJU
Indoor 2 Model Number
CTX12AXVJU
Outdoor Model Number
2MX18AXVJU
System Heating Capacity (BTU)
17,000
System Cooling Capacity (BTU)
17,000
Aplication Area
550 + 550 SqFt
Manufacturer Limited Warranty (years)
10 Year Parts Warranty
Mounting Type
Wall Mount
Voltage System
208/230 V
Efficiency
17 Seer
Application
Heat Pump / Heating & Cooling
System Shipping Weight
117.0
Specifications for model: CTX12AXVJU
Brand
Daikin
Purifiers Air Type
Electronic & HEPA
Type
Central Air Conditioner
Unit Type (Selector)
Standard
Application Area
550 SqFt
Mounting Type
Wall Mounted
[k_4]
1.5
EER (Energy Efficiency Ratio)
10
Electrical
208-230 V; 1 Phase; 60 Hz
Voltage
208/230 Volt
Manufacturer Limited Capacity
10 Year Parts
Ambient Temperature Cooling Range
50°F – 115°F
Ambient Temperature Heating Range
-13°F – 65°F
Certifications
Ahri; ETL
MCA (Minimum Circuit Ampacity)
18.7 amps
MOP (Maximum Overcurrent Protection)
20 amps
Liquid Line Size
1/4 inches
Suction Line Size
3/8 inches
Weight
20 lbs
Depth
9.84 In
Height
11.33 In
Width
30.91 In
Louvers
Yes
Auto Restart
Yes
Automatic Swing
Yes
Colors
White
Convenience Features
Humidistat
DC Inverter Technology
Yes
Filter Cleaning Methods
Washable
Low Temperature Operation
Yes
Matching Outdoor Unit
RXL18UMVJU
Memory
Yes
Remote Control Temperature Sensor
Yes
Shipping Cost
75
Thermostat Type
Wireless Remote
Turbo
Yes
Specifications for model: 2MX18AXVJU
Outdoor Unit Model
2MX18AXVJU
Rated Cooling Conditions (°F DB/WB)
50 / 114.8
Rated Heating Conditions (°F DB/WB)
5 / 64.4
Cooling Capacity (Btu/hr)
17,000
Min/Max Cooling Capacity (Btu/hr)
3,000 / 17,500
Heating Capacity (Btu/hr)
17,000
Min/Max Heating Capacity (Btu/hr)
2,500 / 18,000
SEER
17
HSPF
9.0
EER
10
COP
3.5
Power Supply (V/Hz/Ph)
208-230 / 60 / 1
Min. Circuit Amps MCA (A)
10.9
Max Overcurrent Protection (MOP) (A)
15
Airflow Rate Cooling (H) (CFM)
1,170
Airflow Rate Heating (H) (CFM)
1,300
Liquid Line Size (in)
1/4
Gas Line Size (in)
3/8
Sound Pressure (dBA)
51 / 56
Dimensions (HxWxD) (in)
21-11/16 x 26-1/2 x 11-3/16
Weight (Lbs)
77
{
