- 7 sq. inch display
- Improved blue back light
- Glow in the dark light button
- 5 minute compressor delay protection (selectable on or off)
- Adjustable setpoint limits
- Separate heating and cooling swing (cycle rate) adjustments
- Room temperature calibration adjustments
- Simple private label badge system
- Easy wire color coded terminal blocks
- Universal sub-base
- Mounts on wall or junction box
- Battery or 24v power
- 5 year warranty
Key Specifications
- Pro1
- 2.9 in
- 2.4 in
- 5 years
- Battery & 24 Volt
- Standard
System Specifications
| Control Range Temperature | 44˚F to 90˚F (7˚C to 32˚C) |
|---|---|
| Display Height | 2.9 in |
| Display Width | 2.4 in |
| Illuminated Display | Blue |
| Manufacturer Limited Warranty (years) | 5 years |
| Millivolt Compatible | Yes |
| Mounting Type | Junction Box & Wall |
| Power Source | Battery & 24 Volt |
| Protection | 5 minute compressor delay (selectable on or off) |
| Shipping Time | 24 to 72 hours |
| Terminal Block Configuration | R; C; Y; W; O; B; GH; GL |
| Unit Type (Selector) | Standard |
| User Interface | Push Button |
