Choose the right heating and air conditioning system for your home and you’ll save money upfront, recuperate your investment through lower energy bills or both.
Inverter Powerful Operation- This function boosts cooling or heating performance for a 20 minutes period. It is convenient when it is necessary to change the room temperature quickly.
Swing Compressor- Thanks to its smooth rotation, the swing compressor decreases friction and vibration. It also prevents the leakage of refrigerant gas during compression. These advantages provide quiet and efficient operation.
Flexible performance, rapid response time- After quickly reaching set temperature, the inverter system constantly adjusts and fine-tunes the cooling capacity to prevent undesired temperature swings. Room comfort level is constantly maintained even when the number of people in the room increases or decreases
AHRI Certified; ETL Listed
Additional Features
Indoor Unit On/Off Switch.The unit can be conveniently started by hand if the wireless remote controller is misplaced or its batteries are not charged.
Wireless Remote Controller with Luminous Button- The luminous button absorbs and saves light and then slowly releases it. This makes it easier to see the settings in the dark
Inverter Powerful Operation- This function boosts cooling or heating performance for a 20 minutes period. It is convenient when it is necessary to change the room temperature quickly.
ECO+ Function- An intelligent feature that ensures optimum energy consumption while fulfilling basic human comfort needs. Once activated, set temperature will be adjusted automatically to an eco-friendly level while limiting the maximum power consumption.
Sleep Mode- Unwind at the end of the day with Sleep Mode, which gradually adjust set temperature according to regular sleeping temperature patterns and auto adjust the LED display intensity for an effortlessly personalized sleeping environment.
Wireless Remote Controller with Backlight- The backlit LCD allows easy operation in the dark, convenient for users to identify the functions activated.
LED Display On/Off- The LED Display on unit can be conveniently turned off with the touch of a single button to ensure zero light disturbance
Auto-Restart after Power Failure- The air conditioner memorizes the settings for operation mode, fan speed and temperature setting and automatically returns to them when power is restored after a power failure.
Self-Diagnosis with Digital Display- Malfunction codes can be retrieved and shown on the digital display panel of the wireless remote controller for fast and easy maintenance.
Warranty - 5 years parts, 5 years compressor (if registered)
Advantages of Inverter technology
Superior comfort
Powerful operation
Higher efficiency
Better energy savings
Fixed speed (non-inverter) systems operate by compressor start-stop cycles which consumes more energy and have higher variance of the room temperature
Specifications
Outdoor Unit Model: RXNG09AXVJU
Matching Indoor Unit: FTXNG09AXVJU
Rated Cooling Conditions (°F DB/WB): 50 / 114.8
Rated Heating Conditions (°F DB/WB): 5 / 64.4
Cooling Capacity (Btu/hr): 8,800
Min/Max Cooling Capacity (Btu/hr): 4,400 - 10,200
Heating Capacity (Btu/hr): 9,400
Min/Max Heating Capacity (Btu/hr): 4,400 - 13,000
SEER: 18
HSPF: 9.0
EER: 11
COP: 3.56
Power Supply (V/Hz/Ph): 208-230 / 60 / 1
Airflow Rate Cooling (H) (CFM): 800
Airflow Rate Heating (H) (CFM): 774
Liquid Line Size (in): 1/4
Gas Line Size (in): 3/8
Sound Pressure (Heating/Cooling) (dBA): 46 / 48
Dimensions (HxWxD) (in): 21-11/16 x 26-1/2 x 11-3/16
