Choose the right heating and air conditioning system for your home and you’ll save money upfront, recuperate your investment through lower energy bills or both.
Daikin’s Multi-Zone Systems are ideal for multi-room applications desiring individual room comfort in a space-saving design. With the ability to connect two wall-mounted indoor units to a single outdoor unit, this compact and simple solution can provide additional comfort to spaces where other solutions may not be viable. In addition, with a small outdoor unit footprint, the Daikin CIRRA Multi-Zone unit takes up less space on a patio or balcony (compared to other Daikin Multi-Zone outdoor units). Suitable for new build and renovation projects, Daikin Multi-Zone Systems are an innovative, reliable solution for your home or space.
Features:
10 Years Parts Warranty (Check Manuals & Specification Tables).
Heating Capacity: (5,000 min ~ 18,000 max BTU) 9 HSPF Efficiency
Daikin 2-Zone CIRRA Series has a small condenser cabinet with Blue Fin Protection and anti-corrosion treatment on the heat exchanger. Pre-charged for up to 98-1/2 ft.
Additional Features:
Eco+
Blue Fin Protection
Simplified Maintenance
Anti-Corrosion Treatment on Heat Exchanger
Quick Warming Function
Automatic Defrosting
Reduced size and footprint compared to other Daikin Multi-Zone outdoor units.
Operating Cooling Ranger: 50° - 115°F
Operating Heating Range: 5° - 65°F
Specifications
Outdoor Unit Model: 2MX18AXVJU
SEER: 17
HSPF: 9.0
EER: 10
COP: 3.5
Rated Cooling Conditions (°F DB/WB): 50 / 114.8
Rated Heating Conditions (°F DB/WB): 5 / 64.4
Cooling Capacity (Btu/hr): 17,000
Min/Max Cooling Capacity (Btu/hr): 3,000 / 17,500
Heating Capacity (Btu/hr): 17,000
Min/Max Heating Capacity (Btu/hr): 2,500 -18,000
Power Supply (V/Hz/Ph): 208-230 / 60 / 1
Min. Circuit Amps MCA (A): 10.9
Max Overcurrent Protection (MOP) (A): 15
Airflow Rate Cooling (H) (CFM): 1,170
Airflow Rate Heating (H) (CFM): 1,300
Liquid Line Size (in): 1/4
Gas Line Size (in): 3/8
Sound Pressure (dBA): 51 / 56
Dimensions (HxWxD) (in): 21-11/16 x 26-1/2 x 11-3/16
