Commercial Air Curtain With Electric Heat Creates Protective Barrier to Insects, Pollution and Saves Energy
Maxwell air curtains stabilize indoor environments by producing powerful high-speed air flow dividing the inside and outside environments into two independent temperature zones. They save energy by minimizing air conditioned / heated air losses through opened doorways or areas with continuously opened doors. Attractive and decorative low profile MAFH series effectively repels flying insects, dust and pollutants. The powerful electric heater keeps your occupants comfortable.
Durable galvanized steel casing retains its attractive appearance throughout its life. Directional air flow adjustable louver and convenient two-speed hi-lo fan operation controlled by a unit surface mount switch. The air curtain provides heated air and can circulate ambient air but it does not cool the air.
MAFH036-E2 air curtain can be mounted above or next to doors and openings using included hardware.
- 35.4” W x 8.4” D x 7” H
- 230 V
- Remote control
- Not an air conditioner
- Durable, easy to clean galvanized steel casing
- Features temperature and power surge protection
- Automatically restarts in case of power failure
- 1 year limited manufacturer warranty
WHAT’S INCLUDED
Your Maxwell Air Curtain from Heat & Cool Comes With:
- MAFH039-E2 39" Air Curtain
- Remote Control
- Installation hardware
- 5 foot power cord
- User’s Manual
- Installation Manual
- Manufacturer Warranty
Manufacturer Warranty
- 1 year limited warranty
Key Specifications
- Maxwell
- 22.9 ft/s
- 517 cfm
- 35.4” W x 8.4” D x 7” H
- 60 Hz
- 6 kW
- <57 dB
- 170 W
- Standard
- 208-230 V
System Specifications
| Air Velocity - HI/LO (ft/sec) | 22.9 ft/s |
|---|---|
| Air Volume - HI/LO (cfm) | 517 cfm |
| Dimensions | 35.4” W x 8.4” D x 7” H |
| Frequency | 60 Hz |
| Max Input Power - HI/LO (W) | 6 kW |
| Must ship freight | Yes |
| Noise | <57 dB |
| Power | 170 W |
| Shipping Cost | 0 |
| Shipping Time | 24 to 72 hours |
| Unit Type (Selector) | Standard |
| Voltage | 208-230 V |
